Rim | |
Material | Toray Carbon T700 / T800 |
Outer Width | 28mm |
Hight | 50mm |
ERD | 541mm |
Tubeless | |
Tubeless Model No. | TRU50C-28 |
Inner Width | 21mm |
Tubeless T700 Weight | 1530±50g (DT 350 + Sapim CX-ray ) |
Tubeless T800 Weight | 1480±50g (DT 350 + Sapim CX-ray ) |
Tubeless-Hookless | |
Tubeless-Hookless Model No. | TRU50C-28H |
Inner Width | 22mm |
Tubeless-Hookless T700 Weight | 1530±50g ( DT 350 + Sapim CX-ray ) |
Tubeless-Hookless T800 Weight | 1480±50g ( DT 350 + Sapim CX-ray ) |
Tubular | |
Tubular Model No. | WR50T-28 |
Tubular T700 Weight | 1350±50g (DT 350 + Sapim CX-ray ) |
Tubular T800 Weight | 1270±50g (DT 350 + Sapim CX-ray ) |
700C | |
Tubeless Ultralight Weight | 1400±50g ( DT 350 + Sapim CX-ray ) |
- Model: DT50-CX
Available Options
Rim Shape
T700 Normal Weight Version: 100% Toray T700 Carbon Fiber.
T800 LightWeight Version: Mix 70% Toray T700 and 30% T800 Carbon Fiber.
Ultralight Version: 100% T800 Carbon Fiber. Rider Weight Limited 90kg, UD Paintless Weave Only. Rim Brake Version Weight Will Incrase by 10g.
Superlight T1000 Version: Mix 70% Toray T800 and 30% T1000 Carbon Fiber. No Rider Weight Limited, UD Paintless Weave Only.Rim Brake Version Weight Will Increase by 10g.
Note: Ultralight / Superlight weight is for UD Paintless only, 3K/12K/Marble weight increases 10 g- 15 g .
Note : If you want make Inner Nipple Wheel Must choose Have Rim Groove Hole
Note: Without Rim Groove Holes, The rim do not need use tapes.
If you want make Inner Nipple Wheel Must choose Have Rim Groove Hole
Note: Basalt Brake Surface Rim Weight Increase about 15g
Related
Bicycle Wheel Weight Calculator
Note:
We provide custom assembly wheels building service because have many configurations, so the weight of the wheels need be calculated.
If you need lightweight wheels, please choose lightweight rims, hubs, and spokes.
Use DT 240 Hub,weight increase 50g/pair.
Use Pillar 1423 spokes, weight increase 90g/pair.
Use Pillar 1420 spokes, weight increase 50g/pair.
Use carbon spokes, weight reduce 100g/pair.
For other types of rims, you can purchase a wheel set with the same configuration by selecting the corresponding option.
HUB:DT SWISS 350
SPOKES: Sapim CX-RAY
